| CARACTERISTICI HARDWARE |
| Interfata | 3 Porturi 10/100Mbps LAN,
1 port 10/100Mbps LAN/WAN,
1 Slot pentru Micro card SIM |
| Butoane | Buton WPS/Reset, Buton Wi-Fi On/Off |
| Alimentare Externa | 12V/1A |
| Dimensiuni (L x l x H) | 6.85 × 4.9 × 1.32 in (174 × 124.5 × 33.5 mm) |
| Antena | 2 antene detasabile externe 4G LTE |
| CARACTERISTICI WIRELESS | |
| Standarde Wireless | IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz |
| Frecventa | 2.4 GHz si 5 GHz |
| Rata de Semnal | 300 Mbps in banda de 2.4 GHz, 433 Mbps in banda de 5 GHz |
| Sensibilitate Receptor | 5 GHz:
11a 54M: -78 dBm
11ac VHT20 MCS0: -92 dBm 11ac VHT20 MCS8: -72 dBm
11ac VHT40 MCS0: -90 dBm 11ac VHT40 MCS9: -67 dBm
11ac VHT80 MCS0: -87 dBm 11ac VHT80 MCS9: -64 dBm
2.4 GHz:
11g 54M: -74 dBm
11n HT20 MCS0: -91 dBm 11n HT20 MCS7: -72 dBm
11n HT40 MCS0: -88 dBm 11n HT40 MCS7: -69 dBm |
| Putere de Transmisie | < 20 dBm (2.4 GHz), < 23 dBm (5 GHz) |
| Functii Wireless | Activare/Dezactivare Emisie Wireless, WMM, Statistici Wireless |
| WAN Failover | Da |
| Securitate Wireless | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Tip de retea | 4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800 MHz)
TDD-LTE B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900 MHz) |
| CARACTERISTICI SOFTWARE |
| Calitatea Serviciului | Prioritizeaza traficul de retea in functie de dispozitiv sau aplicatie |
| Moduri Operare | 3G/4G Router, Wireless Router |
| Tip WAN | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management | Control acces, management local, management de la distanta, reboot schedule |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| DNS Dinamic | DynDns, NO-IP, TP-Link DDNS |
| Control Acces |
| Securitate Firewall | DoS, SPI Firewall, IP and MAC Address Binding |
| Protocoale | Supports IPv4 and IPv6 |
| Guest Network | x 1 2.4GHz retea vizitatori, x 1 5GHz retea vizitatori |
| VPN Server | PPTP VPN, OpenVPN |
| ALTELE |
| Certificari | CE, RoHS |
| Continut Pachet | AC750 Router Wireless 4G LTE Dual Band
Cablu Ethernet RJ45
Adaptor alimentare
Ghid de Instalre Rapida |
| Cerinte de sistem | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX sau Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 sau alt browser Java
Card Micro SIM |
| Mediu | Temperatura de operare: 0°C~40°C (32°F ~104°F)
Temperatura de depozitare: -40°C~60°C (-40°F ~140°F)
Umiditate de operare: 10%~90% fara condensare
Umiditate de depozitare: 5%~90% fara condensare |
