| Compresie video | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Intrare video analogica | 8-canale |
| Intrare HDTVI | 1080p25, 1080p30, 720p25, 720p30 |
| Intrare AHD | 1080p25, 1080p30, 720p25, 720p30 |
| Intrare HDCVI | 1080p25, 1080p30, 720p25, 720p30 |
| Intrare CVBS | Support |
| Intrare video IP | 2 canale (pana la 10 canale) Rezolutie de pana la 5 MP Suport camere IP H.265+/H.265/H.264+/H.264 |
| Compresie audio | G.711u |
| Intrare audio | RCA 1 canal (2,0 Vp-p, 1 KΩ)
8 canale prin cablu coaxial |
| Iesire HDMI/VGA | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI/VGA simultaneous output |
| Rezolutie de codificare | Cand modul 1080p Lite nu este activat: 720p/WD1/4CIF/VGA/CIF
Cand modul 1080p Lite este activat: 1080p Lite/HD 720p Lite/WD1/4CIF/VGA/CIF |
| Fluxul principal Rata de cadre | Cand modul 1080p Lite nu este activat: Pentru acces la flux 720p: 720p/WD1/4CIF/VGA/CIF@15 fps; Pentru acces la fluxul SD: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Cand modul 1080p Lite este activat: 1080p Lite/HD 720p Lite/WD1/4CIF/VGA/CIF@15 fps |
| Rata de cadre sub-stream | CIF/QVGA@25 fps (P)/30 fps (N) |
| Rata de transfer video | 32 Kbps to 4 Mbps |
| Iesire audio | 1 canal, RCA (liniar, 1 KΩ) |
| Rata de biti audio | 64 Kbps |
| Flux dublu | A sustine |
| Tipul fluxului | Video, Video si Audio |
| Redare sincrona | 8-ch |
| Protocoale de retea | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Interfata SATA | 1 interfata SATA |
| Capacitatea hard diskului | Capacitate de pana la 4 TB pentru fiecare disc |
| Intrare audio bidirectionala | Reutilizati prima intrare audio |
| Interfata retea | 1, interfata Ethernet autoadaptabila RJ45 10/100 Mbps |
| interfata USB | Panoul din spate: 2 × USB 2.0 |
| Alimentare electrica | 12 VDC, 1,5 A |
| Consum (fara HDD) | ≤ 17 W |
| Temperatura de lucru | -10 °C pana la 55 °C (14 °F pana la +31 °F) |
| Umiditatea de lucru | 10% pana la 90% |
| Dimensiuni (L × A × H) | 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
| Greutate (fara HDD) | ≤ 1 kg (2.2 lb) |
