| Compresie video |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Intrare video analogica |
4-ch
Interfata BNC (1,0 Vp-p, 75 Ω), care accepta conexiunea coaxitron
|
| Intrare HDTVI |
8 MP@15 fps, 8 [email protected] fps, 3K@20 fps, 5 MP@20 fps, 5 MP@12 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
|
| Intrare AHD |
5 MP@20 fps, 4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
| Intrare HDCVI |
4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
|
| Intrare CVBS |
PAL/NTSC |
| Intrare video IP |
2 canale (pana la 6 canale)
Mod IP imbunatatit activat: 4 canale (pana la 8 canale), fiecare pana la 4 Mbps
Rezolutie de pana la 8 MP
Accepta camere IP H.265+/H.265/H.264+/H.264
|
| Compresie audio |
G.711u |
| Intrare audio |
1 canal, RCA (2,0 Vp-p, 1 KΩ)
4 canale prin cablu coaxial |
| Iesire HDMI/VGA |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
| Rezolutie de codificare |
8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
|
| Fluxul principal Rata de cadre |
Fluxul principal:
8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N )
*: 8 MP@8 fps este disponibil numai pentru canalul 1.
|
| Rata de cadre sub-stream |
WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Rata de transfer video |
32 Kbps to 10 Mbps |
| Iesire audio |
1 canal, RCA (liniar, 1 KΩ) |
| Rata de biti audio |
64 Kbps |
| Flux dublu |
A sustine |
| Tipul fluxului |
Video, Video si Audio |
| Redare sincrona |
4-ch |
| Protocoale de retea |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
| Interfata SATA |
1 interfata SATA |
| Capacitatea hard diskului |
Capacitate de pana la 10 TB pentru fiecare disc |
| Intrare audio bidirectionala |
1 canal, RCA (2,0 Vp-p, 1 KΩ) (folosind prima intrare audio)
|
| Interfata retea |
1, interfata Ethernet auto-adaptabila RJ45 10M/100M
|
| interfata USB |
2 × USB 2.0 |
| Alimentare electrica |
12 VDC, 1,5 A |
| Consum (fara HDD) |
≤ 15 W (fara HDD) |
| Temperatura de lucru |
De la -10 °C la +55 °C (de la +14 °F la +131 °F) |
| Umiditatea de lucru |
10% pana la 90% |
| Dimensiuni (L × A × H) |
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
| Greutate (fara HDD) |
≤ 1.16 kg (fara HDD, 2.6 lb.) |
