| Compresie video |
H.264+/H.264 |
| Intrare video analogica |
4-ch |
| Intrare HDTVI |
1080p25, 1080p30, 720p25, 720p30 |
| Intrare AHD |
1080p25, 1080p30, 720p25, 720p30 |
| Intrare HDCVI |
1080p25, 1080p30, 720p25, 720p30 |
| Intrare CVBS |
A sustine |
| Intrare video IP |
1 canal (pana la 5 canale) |
| Compresie audio |
G.711u |
| Intrare audio |
1 canal, RCA (2,0 Vp-p, 1 KΩ)
4 canale prin cablu coaxial |
| Iesire HDMI/VGA |
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
| Rezolutie de codificare |
Cand modul simplificat 1080p nu este activat: 720p/WD1/4CIF/VGA/CIF
Cand modul 1080p lite este activat: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF
|
| Fluxul principal Rata de cadre |
Cand modul 1080p lite este activat: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Cand modul simplificat 1080p nu este activat: Pentru acces la flux 720p: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Pentru acces la flux SD: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
|
| Rata de cadre sub-stream |
2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N) |
| Rata de transfer video |
32 Kbps to 4 Mbps |
| Iesire audio |
1-ch, RCA (Linear, 1 KΩ) |
| Rata de biti audio |
64 Kbps |
| Flux dublu |
suporta |
| Tipul fluxului |
Video, Video si Audio |
| Redare sincrona |
4-ch |
| Conexiuni la distanta |
32 |
| Protocoale de retea |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
|
| Interfata SATA |
1 interfata SATA |
| Capacitatea hard diskului |
Capacitate de pana la 6 TB pentru fiecare disc |
| Intrare audio bidirectionala |
1 canal, RCA (2,0 Vp-p, 1 KΩ) |
| Interfata retea |
1, interfata Ethernet autoadaptabila RJ45 10M/100M |
| interfata USB |
Panoul din spate: 2 × USB 2.0 |
| Alimentare electrica |
12 VDC |
| Consum (fara HDD) |
≤ 8 W |
| Temperatura de lucru |
-10 °C pana la +55 °C (14 °F pana la 131 °F) |
| Umiditatea de lucru |
10% pana la 90% |
| Dimensiuni (L × A × H) |
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
| Greutate (fara HDD) |
≤ 0.8 kg (1.8 lb) |
