Model

M6204

Procesor

HuaWei HI3515

Sistem operare

Embedded LINUX

Resurse

Multiple channels realtime recording,playback,network operation and USB backup

Interfata

GUI,on-screen menu tips

Display

1/4 screen

Standard

PAL(625 line,50f/s); NTSC（525 line,60f/s)

Compression

H.264(Main Profile)

Compresie

TV: D1

Vizualizare inreg.

D1/HD1/CIF/QCIF

Codare

100/120fps D1

Compresie

G711A

Inregistrare

Manual>Alarma>Detectie>Orar

Vizualizare canale

1～4

Record Search

Time/Date,Alarm,Motion Detection & exact search(accurate to second)

HDD Occupation

Video: CIF 4~5G/day/channel, D1 16~20G/day/channel

Audio: 691.2M/day/channel

Record Storage

Local HDD , SD card 2 bucati

Backup

Network/USB / HDD/USB DVD-RW/SATA DVD-RW/SD card

Intrari video

4 canale

Iesire video

1 canal BNC

Intrari audio

4ch

Ieisiri audio

1ch RCA(200-3000mV,5K)

Network

RJ45 10M/100M

PTZ

 1 RS485

USB

1 USB

SD card

2 SD card (Max 2 x 32G,for regular record,redundancy record, backup, snapshot etc...)

GPIO

Support speed,turn light,brake signals input;vehicle information OSD overlay,storage etc...

GPS

Built-in GPS module,Support GPS data overlay,timing etc...

3G

Built-in 3G module, support EVDO,WCDMA,TD-SCDMA, support auto registration and upload; perfect sub stream network transmitting to keep fluent and stable videos in remote monitoring.

Others

Support timing and delay boot up/shut down

Player

Mobile DVR player,support google map,show vehicle running track and data

Platform

Support auto registration, no need router mapping,support google map,show vehicle running track and data

SDK

Free SDK

Alimentare

 Intre 6V~40V

Dimensiuni

170mm * 139mm*40mm

Greutate

730g
