| Compresie video | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Rezolutie de codificare | Cand modul 8 MP Lite nu este activat: 8 MP/5 MP/4 MP/1080p/720p/WD1/4CIF/VGA/CIF Cand modul 8 MP Lite este activat: 8 MP Lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Rata de cadre | Flux principal: Cand modul 8 MP Lite nu este activat: 8 MP@8 fps/5 MP@12 fps/4 MP@15 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps este valid doar pentru canalul 1 de la HWD-7104MH-G3. Cand modul 8 MP Lite este activat: 8 MP Lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF@15 fps
*: 8 MP Lite este valid doar pentru HWD-7104MH-G3. Sub-flux: WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Rata de transfer video | de la 32 Kbps pana la 10 Mbps |
| Flux dublu | Suport |
| Tipul de flux | Video, Video & Audio |
| Compresie audio | G.711u |
| Rata de biti audio | 64 Kbps |
| Intrare video IP | 4 canale (poate ajunge la 8 canale).
Pana la o rezolutie de 8MP. Accepta camere IP H.265+/H.265/H.264+/H.264. |
| Intrare video analogica | 4 canale Interfata BNC (1.0 Vp-p, 75 Ω), care accepta conexiunea coaxitron. |
| Intrare HDTVI | 8 MP, 5 MP, 4 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 |
| Intrare AHD | 5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| Intrare HDCVI | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| Intrare CVBS | PAL/NTSC |
| Iesire VGA | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| Iesire HDMI | 1-ch, 1920 × 1080/60 Hz, 1280 ×
1024/60 Hz, 1280 × 720/60 Hz, 1024 ×
768/60 Hz |
| Intrare audio | 1 canal, RCA (2.0 Vp-p, 1 KΩ)
4 canale prin cablu coaxial |
| Iesire audio | 1 canal, RCA (liniar, 1 KΩ) |
| Intrare audio bidirectionala | 1 canal, RCA (2.0 Vp-p, 1 KΩ)(folosind intrarea audio) |
| Redare sincrona | 4 canale |
| Retea | |
| Conexiune la distanta | 32 |
| Protocoale de retea | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Interfata retea | 1, RJ45 10/100 Mbps interfata Ethernet auto-adaptabila |
| Interfata auxiliara | |
| Interfata SATA | 1 interfata SATA |
| Capacitatea hard diskului | Capacitate de pana la 10 TB pentru fiecare disc |
| interfata USB | Panou real: 2 × USB 2.0 |
| Intrare/iesire alarma | N/A |
| General | |
| Alimentare electrica | 12 VDC, 1.5 A |
| Consum (fara HDD) | ≤ 10 W |
| Temperatura de lucru | De la -10 °C la 55 °C (de la 14 °F la 131 °F) |
| Umiditatea de lucru | 10% pana la 90% |
| Dimensiuni (L × A × H) | 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
| Greutate (fara HDD) | ≤ 1 kg (2.2 lb.) |
