Deep learning-based motion detection 2.0 is enabled by default for all analog channels; it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights. Quick search by object or event type is supported. |
Up to 4-ch Human/Vehicle Analysis |
Facial Detection |
|
Facial Detection and Capture |
Face picture detection, face picture search |
Recording |
|
Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
Encoding Resolution |
8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
Frame Rate |
Main stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available for channel 2 to channel 4. Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
Video Bitrate |
32 Kbps to 10 Mbps |
Dual-stream |
Support |
Stream Type |
Video, Video & Audio |
Audio Compression |
G.711u |
Audio Bitrate |
64 Kbps |
Video and Audio |
|
IP Video Input |
2-ch (up to 6-ch) Enhanced IP mode on: 4-ch (up to 8-ch), each up to 4 Mbps Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
Analog Video Input |
4-ch BNC interface (1.0 Vp-p, 75 ohm), supporting coaxitron connection |
HDTVI Input |
8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 3 MP@18 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps |
AHD Input |
5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
HDCVI Input |
8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
CVBS Input |
PAL/NTSC |
HDMI Output |
1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
Video Output Mode |
HDMI/VGA simultaneous output |
Audio Input |
1-ch, RCA (2.0 Vp-p, 1 K ohm) 4-ch via coaxial cable |
Audio Output |
1-ch, RCA (Linear, 1 K ohm) |
Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 K ohm) (using the first audio input) |
Synchronous Playback |
4-ch |
Network |
|
Total Bandwidth |
96 Mbps |
Remote Connection |
32 |
Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
Network Interface |
1, RJ45 10M/100M self-adaptive Ethernet interface Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle through USB interface |
Auxiliary Interface |
|
SATA |
1 SATA interface Capacity: Up to 10 TB capacity for each disk |
Alarm In/Out |
N/A |
USB Interface |
2 × USB 2.0 |
General |
|
Power Supply |
12 VDC, 1.5 A |
Consumption |
≤ 15 W (without HDD) |
Working Temperature |
-10 °C to +55 °C (+14 °F to +131 °F) |
Working Humidity |
10% to 90% |
Dimension |
200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) |
