| Senzor imagine | 2 MP CMOS |
| Rezolutie maxima | 1920 (H) × 1080 (V) |
| Sistem scanare | Progressive |
| Viteza obturator electronic | 1/25 s–1/100,000 s (PAL), 1/30 s–1/100,000 s (NTSC) |
| Iluminare minima | 0.01 [email protected] (Color), 0.001 [email protected] (B/W), 0 lux (IR on) |
| Raport S/N | >65 dB |
| Distanta iluminare IR/warm light | Pana la 30 m |
| Numar LED-uri | 2 (multi-core) |
| Control iluminare | Automat/manual |
| Lentila | Fixa, 2.8 mm |
| Montura lentila | M12 |
| Diafragma maxima | F2.0 |
| Camp vizual (2.8 mm) | H: 102°, V: 60°, D: 129° |
| Distanta focalizare minima | 0.5 m (2.8 mm) |
| Rata cadre video | 1080p@25fps (PAL), 1080p@30fps (NTSC) |
| Moduri video | CVI, TVI, AHD, CVBS |
| Mod zi/noapte | Auto (ICR) / Color / B/W |
| Functii imagine | BLC, HLC, DWDR, 3D NR, balans alb, gain auto/manual |
| Mod iluminare | Smart IR & WL / doar IR / doar WL |
| Mascare intimitate | Activare/dezactivare – max. 8 zone |
| Microfon integrat | Da |
| Distanta preluare audio | Pana la 8 m |
| Alimentare | 12 VDC (±30%) |
| Consum | Max. 2.6 W (cu IR activ) |
| Temperatura functionare | –40 °C pana la +60 °C |
| Umiditate | <95% RH (fara condens) |
| Protectie | IP67 |
| Material carcasa | Metal |
