| Tip senzor |
2 MP CMOS |
| Rezolutie maxima |
1920 (H) × 1080 (V) |
| Sistem de scanare |
Progresiv |
| Timp de expunere electronic |
PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s |
| Iluminare minima |
0.01 [email protected] (color), 0.001 [email protected] (alb/negru), 0 lux cu iluminator activ |
| Raport S/N |
>65 dB |
| Distanta iluminare |
30 m |
| Control iluminator |
Auto / Manual |
| Numar LED-uri |
2 (lumina multi-core) |
| Ajustare unghi |
Pan: 0°–360°, Tilt: 0°–90°, Rotatie: 0°–360° |
| Tip lentila |
Fixa |
| Montura lentila |
M12 |
| Lungime focala |
2.8 mm |
| Deschidere maxima |
F2.0 |
| Camp vizual |
2.8 mm: H: 111.3°, V: 60.8°, D: 134.2° |
| Distanta focus minima |
2.8 mm: 0.5 m |
| DORI (2.8 mm) |
Detectare: 40.6 m, Observare: 16.2 m, Recunoastere: 8.1 m, Identificare: 4.1 m |
| DORI (3.6 mm) |
Detectare: 49.9 m, Observare: 20.0 m, Recunoastere: 10.0 m, Identificare: 5.0 m |
| Rata cadre video |
1080p@25/30 fps (CVI/AHD/TVI), 960H (CVBS) |
| Rezolutii suportate |
1080p (1920 × 1080), 960H (960 × 576 / 960 × 480) |
| Zi/Noapte |
Auto(ICR) / Color / Alb-Negru |
| BLC |
BLC, HLC, WDR |
| WDR |
DWDR |
| Balans de alb |
Auto |
| Control castig |
Auto / Manual |
| Reducere zgomot |
3D NR |
| Mod iluminare |
Smart IR & WL, Mod WL, Mod IR |
| Oglindire imagine |
Da |
| Certificari |
CE-LVD: EN 62368-1, CE-EMC: EN 55032, EN 55035 |
| Microfon integrat |
Da, pana la 8 m |
| Audio camera |
CVI, TVI |
| Comunicare bidirectionala |
Da |
| Difuzor |
Da, pana la 8 m |
| Tip iesire video |
CVI / TVI / AHD / CVBS prin BNC (comutabil prin DIP switch) |
| Alimentare |
12 VDC (±30%) |
| Consum |
Max 6.6 W (IR activ) |
| Temperatura functionare |
-40°C pana la +60°C |
| Umiditate functionare |
<95% RH, fara condens |
| Temperatura stocare |
-40°C pana la +60°C |
| Protectie |
IP67 |
| Protectie anticoroziva |
Protectie de baza |
| Material carcasa |
Plastic |
| Dimensiuni produs |
161.6 mm × 69.7 mm × 70.0 mm |
| Greutate neta |
0.20 kg |
| Greutate bruta |
0.29 kg |
| Montaj |
Pe perete, tavan, stalp vertical |
