| Senzor imagine | 5 MP CMOS |
| Rezolutie maxima | 2880 (H) × 1620 (V) |
| Sistem de scanare | Progresiv |
| Viteza obturator electronic | PAL: 1/25 s – 1/100,000 s, NTSC: 1/30 s – 1/100,000 s |
| Iluminare minima | 0.02 [email protected] (color), 0.002 [email protected] (B/W), 0 lux (IR pornit) |
| Distanta iluminare IR | 30 m (98.43 ft) |
| Numar LED-uri IR | 3 |
| Reglaj unghi | Pan: 0°–360°, Tilt: 0°–90°, Rotire: 0°–360° |
| Tip lentila | Focala fixa |
| Montura lentila | M12 |
| Distanta focala | 2.8 mm, 3.6 mm, 6 mm |
| Diafragma maxima | F2.0 |
| Unghi de vizualizare (2.8 mm) | Orizontal: 106°, Vertical: 56°, Diagonal: 125° |
| Unghi de vizualizare (3.6 mm) | Orizontal: 92°, Vertical: 48°, Diagonal: 109° |
| Distanta focalizare minima (2.8 mm) | 1.0 m (3.28 ft) |
| Distanta focalizare minima (3.6 mm) | 1.3 m (4.27 ft) |
| Compresie video | H.265, H.264 |
| Cadre video | 5 MP la 25 fps (PAL), 5 MP la 30 fps (NTSC) |
| Mod zi/noapte | Auto(ICR), Color, B/W |
| Reducere zgomot | 2D NR |
| Protectie | IP67 |
| Alimentare | 12 VDC ± 30% |
| Consum de energie | Max. 3.7 W |
| Temperatura de operare | -40 °C ~ +60 °C |
| Umiditate de operare | <95% RH, fara condens |
| Material carcasa | Plastic |
