| Rezolutie |
2 MP, 1920 × 1080 |
| Senzor de imagine |
2 MP CMOS |
| Lentila |
2.8 mm |
| Camp vizual (FOV) |
2.8 mm: 106.4° H / 57.9° V / 124.6° D |
| Montura lentila |
M12 |
| Iluminare minima |
0.01 Lux (F1.2, AGC ON), 0 Lux cu IR |
| Distanta IR |
Pana la 20 metri |
| Mod zi/noapte |
ICR (filtru IR mecanic) |
| WDR |
DWDR (Wide Dynamic Range digital) |
| Functii suplimentare |
BLC, HLC, 2D DNR, Smart IR, AGC, balans de alb |
| Moduri de iesire video |
TVI/AHD/CVI/CVBS (comutabil) |
| Rata de cadre |
1080P@25/30fps (TVI, AHD, CVI) |
| Shutter |
1/25s - 1/50,000s (PAL), 1/30s - 1/50,000s (NTSC) |
| Alimentare |
12 VDC ± 25% |
| Consum |
Max. 2.2 W |
| Temperatura functionare |
-40°C pana la +60°C |
| Protectie |
IP67 (exterior) |
| Material carcasa |
Plastic |
| Dimensiuni |
Φ70 × 137.8 mm |
| Greutate |
Aproximativ 150 g |
| Ajustare unghi |
Pan: 0–360°, Tilt: 0–90°, Rotatie: 0–360° |
| Comunicare |
Protocol HIKVISION-C |
