| Rezolutie |
2 MP, 1920 × 1080 |
| Senzor imagine |
2 MP CMOS |
| Sistem semnal |
PAL/NTSC |
| Rata cadrelor |
TVI/AHD/CVI: 1080P@30fps/25fps; CVBS: PAL/NTSC |
| Iluminare minima |
0.01 Lux@(F1.2, AGC ON), 0 Lux cu IR |
| Timp de expunere |
PAL: 1/25 s – 1/50,000 s; NTSC: 1/30 s – 1/50,000 s |
| Lentila |
2.8 mm / 3.6 mm / 6 mm (fixa) |
| Unghi vizualizare (2.8 mm) |
Orizontal: 106.4°, Vertical: 57.9°, Diagonal: 124.6° |
| Montura lentila |
M12 |
| Iluminator IR |
Pana la 25 m (Smart IR) |
| Mod zi/noapte |
ICR, Auto/Color/Alb-Negru |
| WDR |
Digital WDR (DWDR) |
| Reducere zgomot imagine |
2D DNR |
| Functii imagine |
Luminozitate, Claritate, Smart IR |
| Moduri expunere automata |
DWDR, BLC, HLC, Global |
| Balans de alb |
Automat / Manual |
| Ajustare unghi |
Pan: 0°–360°, Tilt: 0°–90°, Rotatie: 0°–360° |
| Video output |
Comutabil: TVI / AHD / CVI / CVBS |
| Alimentare |
12 VDC ± 25% |
| Consum maxim |
3 W |
| Conditii functionare |
-40°C ~ +60°C, umiditate ≤ 90% (fara condens) |
| Grad de protectie |
IP67 (exterior, rezistenta la apa si praf) |
| Material carcasa |
Metal |
| Dimensiuni |
Φ 70 mm × 137.8 mm |
| Greutate |
Aprox. 260 g |
| Compatibilitate control |
HIKVISION-C |
