| Senzor imagine |
5 MP CMOS |
| Rezolutie maxima |
2560 (L) × 1944 (A) |
| Iluminare minima |
0.01 Lux@(F2.0, AGC ON), 0 Lux cu IR |
| Timp de expunere |
PAL: 1/25 s pana la 1/50, 000 s NTSC: 1/30 s pana la 1/50, 000 s |
| Day & Night (Zi & Noapte) |
ICR |
| Ajustare unghi |
Pan: 0 pana la 360°, Tilt: 0 pana la 75°, Rotire 0 pana la 360° |
| Sistem de semnal |
PAL/NTSC |
| Lentila |
Tip lentila: 2.8 mm |
| Focalizare & Camp vizual |
2.8 mm, FOV orizontal: 85.5°, FOV vertical: 63.7°, FOV diagonal: 110.7° |
| Parametri imagine |
Comutare STD/HIGH-SAT |
| Setari imagine |
Luminozitate, Claritate, Oglinziere, Smart IR |
| Rata de cadre |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
| Mod Day/Night |
Auto/Culoare/Negru si Alb |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Balans de alb |
ATW/MANUAL |
| Control automat de gain (AGC) |
Suportat |
| Interfata |
Iesire video comutabila TVI/AHD/CVI/CVBS |
| Material |
Carcasa: Plastic Corp principal: Metal |
| Dimensiune |
Φ 109.82 mm × 91.03 mm (Φ 4.32" × 3.6") |
| Greutate |
Aprox. 300 g (0.66 lb.) |
| Conditii de operare |
-40° C pana la 60° C (-40° F pana la 140° F), Umiditate 90% sau mai putin (fara condens) |
| Comunicare |
HIKVISION-C |
| Limba |
Engleza |
| Sursa de alimentare |
12 VDC ± 25% |
| Consum |
Maxim 3.7 W |
| Distanta IR |
Pana la 40 m |
| Aprobare |
Protectie IP67 |
