Product name:	INIM Previdia-C050SG
Name on certification:	PREVIDIA-C050SG
Loop(s) on central panel:	1
Maximum number of loops	1
Maximum device number per loop:	64
Zones maximum:	1000
Extinguishing:	-
Supervisory software:	built in map system and it is compatible with SmartLook
Built-in keyboard:	Yes
Built-in LCD display:	yes (color TFT touchscreen)
Built-in LED panel:	-
Connectable repeater:	max. 47pcs on Hornet+ network
Connectable repeater:	-
Connection to fire detection system token-ring network:	In Hornet+ network (standard equipment)
Firmware:	1.xx
Available protocols:	Inim Enea; Argus Vega; Apollo XP95/Discovery
Suggested detectors:	Inim Enea; Argus Security Vega; Apollo XP95 and Discovery
Operating voltage:	230V~ (+10% - 15%) 50/60 Hz
Max current draw on AC input:	0.6A @ 230V
Panel Current draw (motherboard+display; attachment panel see at products):	150mA
Panel Current draw (motherboard+display; attachment bords see at products) at alarm:	170mA
Max current available for external load:	1,5A load + 0,6A battery-charge
Rechargeable batteries:	2 pcs 12 V 7 Ah
Alarm output:	It have 4 programmable I6O terminals
Fault output:	NO/NC/C relay and it have 4 programmable I6O terminals
Dialer:	option with C-DIAL internal module
Built-in printer:	-
LAN connection:	Standard equipment
Dimensions:	322 x 324 x 86 mm
Operating temperature:	-5°C / +40°C
