| Camera |
| Senzor de imagine: |
1/2.8" Progressive Scan CMOS |
| Rezolutie: |
1920(H)x1080(V) |
| Sistem: |
PAL/NTSC |
| Iluminare minima: |
F1.6, AGC On: Color: 0.05 lux, B/W : 0.01 lux, 0 lux cu IR |
| Balans de alb: |
Auto/Manual/ATW/Interior/Exterior/Incandescent/Fluorescent |
| AGC: |
Auto/Manual |
| BLC: |
Pornit/Oprit |
| HLC: |
Support |
| WDR: |
Support |
| Obturator: |
1-1/10,000s |
| Day& Night: |
ICR |
| Zoom digital |
16X |
| Masca: |
8 masti de privatiune programabile. |
| Auto Focus: |
Auto / Semi-automatic / Manual |
| Lentila |
| Lungime focala: |
4.8-120mm, 25x |
| Viteza zoom |
Aprox.3secunde de la max la min.(Optical Wide~Tele) |
| Unghi: |
58.3-3.2 grade (Wide~Tele) |
| Distanta minima de focus: |
10~1,000mm(Wide~Tele) |
| Gama apertura |
F1.6~F3.5 |
| Pan & Tilt |
| Raza Pan: |
360° |
| Viteza Pan : |
Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s |
| Raza Tilt: |
-15°-90° (Auto Flip ) |
| Viteza Tilt: |
Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s |
| Zoom proportional: |
Viteza de rotatie adjustata la zoom |
| Preseturi: |
300 |
| Patrule: |
8 patrols, up to 32 presets per patrol |
| Actiuni: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: |
ON/OFF |
| Infrarosu |
| Distanta IR: |
150m |
| Focusare IR : |
Adjustabil din zoom |
| Retea |
| Ethernet: |
10Base -T, /100Base-TX, RJ45 Connector |
| Rata de cadre: |
50Hz:25fps(1920×1080), 25fps (1280×720),
60Hz:30fps(1920×1080), 30fps (1280×720) |
| Stream principal: |
50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720) |
| Stream secundar: |
50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288)
60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240) |
| Al 3 -lea stream: |
50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)
60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) |
| Compresie: |
H.264 / MJPEG |
| Codare ROI: |
Support 4 areas with adjustable levels |
| Protocol comunicare: |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, |
| Nr. utilizatori simultani: |
Pana la 20 utilizatori |
| Dual Stream: |
Suporta |
| Niveluri utilizatori: |
Pana la 32 users,3 Nivele: Administrator, Operator si utilizator |
| |
|
| General |
| Limba: |
Engleza |
| Alimentare: |
24 VDC |
| Consum: |
Max.20W |
| Temperatura functionare/Umiditate: |
-30°C ~ 65°C (-22°F ~ 149°F) |
| Grad protectie |
IP66 standard |
| Montaj: |
Include brat montaj 1602ZJ |
| Dimensiuni: |
Φ208(mm)×305(mm) |
| Greutate (approx.): |
3.3kg |
