| Intrare Video/Audio |
| Intrare audio |
1 |
| Compresie video |
H.265+/H.265/H.264+/H.264 |
| Intrare video Analog si HD-TVI |
8 interfete BNC (1.0Vp-p, 75 Ω) |
| Camere compatibile |
HDTVI: 3MP (Doar pe primele 2 canal) ,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, |
| AHD: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz |
| HDCVI: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz |
| CVBS |
| IP (ONVIF, PSIA, HIKVISION) Maxim 2 camere IP |
| Interfata intrare Video |
BNC (1.0 Vp-p, 75Ω) |
| Compresie audio |
G.711u |
| Intrare: |
RCA (2.0 Vp-p, 1 kΩ) |
| Audio bi-directional: |
1, RCA (2.0 Vp-p, 1 KΩ), (utilizand primul canal al intrarii audio) |
| Iesire Video/Audio |
| Iesire CVBS |
1, BNC(1.0Vp-p,75Ω),rezolutie:PAL:704x576,NTSC:704x480 |
| Iesire HDMI/VGA |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Rezolutie inregistrare |
Cand modul 1080p Lite nu este activ: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; |
| Cand modul 1080p Lite este activat: 3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF |
| Frame rate |
Cand modul 1080p Lite nu este activ: |
| Pentru acces stream 3 MP: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps |
| Pentru acces stream 1080p: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Pentru acces stream 720p: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Cand modul 1080p Lite este activat: |
| 3 MP@15fps FULL HD @15FPS |
| 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Sub-stream: |
| WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Video Bit Rate |
32 Kbps-6 Mbps |
| Tip Stream |
Video/Video&Audio |
| Audio bi-directional: |
1, RCA (2.0 Vp-p, 1 kΩ) (utilizand intrarea audio) |
| Iesire audio |
1 RCA(Linear, 1kΩ) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Da |
| Rezolutie redare |
3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
| Vizualizare simultana |
8-ch |
| Management retea |
| Conexiuni de la distanta |
128 |
| Protocoale retea |
TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
| Hard Disk |
| Interfata intrare Video |
1 SATA |
| Capacitate: |
capacitate maxima 6 TB |
| Interfata externa |
| Interfata retea |
1; 10M / 100M Ethernet |
| USB |
2 x USB 2.0 |
| Serial |
1; standard RS-485 serial, half-duplex |
| General |
| Alimentare |
12 VDC |
| Consum: |
≤ 7.5W (fara hard disks) |
| Temperatura operare |
-10 ºC to +55 ºC (14 ºF to 131 ºF) |
| Umiditate operare: |
10% to 90% |
| Dimensiuni: |
315 × 242 × 45 mm |
| Greutate |
≤ 1.78 kg |
