| Image Sensor |
1/2.8" progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON) |
| |
B/W: 0.001 Lux @(F1.6, AGC ON) |
| |
0 Lux with IR |
| White Balance |
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC |
Auto/Manual |
| Shutter Time |
1/1 s to 1/30,000 s |
| Day & Night |
IR Cut Filter |
| Digital Zoom |
16x |
| Privacy Mask |
24 programmable privacy masks |
| Focus Mode |
Auto/Semi-automatic/Manual |
| WDR |
120 dB WDR |
| Lens |
Focal Length 4.8 mm to 120 mm, 25x optical |
| |
Zoom Speed Approx. 3.2 s (optical lens, wide-tele) |
| FOV |
Horizontal field of view: 57.6°to 2.5°(wide-tele) |
| |
Vertical field of view: 34.4°to 1.4°(wide-tele) |
| |
Diagonal field of view: 64.5°to 2.9°(wide-tele) |
| Working Distance |
10 mm to 1500 mm (wide-tele) |
| Aperture Range |
F1.6 to F3.5 |
| IR |
IR Distance 100 m |
| |
Smart IR Support |
| PTZ |
Movement Range (Pan) 360° endless |
| |
Pan Speed Configurable, from 0.1°/s to 80°/s |
| |
Preset Speed: 80°/s |
| |
Movement Range (Tilt) From -15° to 90°(Auto-flip) |
| |
Tilt Speed Configurable, from 0.1°/s to 80°/s |
| |
Preset Speed: 80°/s |
| |
Proportional Zoom Support |
| |
Presets 300 |
| |
Patrol Scan 8 patrols, up to 32 presets for each patrol |
| |
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan |
| |
Power-off Memory Support |
| |
Park Action Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| |
PTZ Position Display Support |
| |
Preset Freezing Support |
| |
Scheduled Task Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust |
| Compression Standard |
Video Compression |
| |
Main Stream: H.265+/H.265/H.264+/H.264 |
| |
Sub-Stream: H.265/H.264/MJPEG |
| |
Third Stream: H.265/H.264/MJPEG |
| |
H.264 Type Baseline Profile/Main Profile/High Profile |
| |
H.264+ Support |
| |
H.265 Type Main Profile |
| |
H.265+ Support |
| |
Video Bitrate 32 Kbps to 16384 Kbps |
| Audio Compression |
G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
| Audio Bitrate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2) |
| |
SVC Support |
| Smart Feature |
Basic Event Detection |
| |
Motion Detection, Video Tampering Detection, Exception Detection |
| Smart Event Detection |
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection, Audio Exception Detection |
| ROI encoding |
Main stream, sub-stream and third stream respectively support four fixed areas. |
| Smart Record |
ANR (Automatic Network Replenishment), Dual-VCA |
| Image |
Max. Resolution 1920 × 1080 |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| |
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) |
| |
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) |
| |
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Image Enhancement |
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
| Network |
Network Storage |
| |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API |
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users. |
| |
3 levels: Administrator, Operator and User |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Client |
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| Web Browser |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 |
| Interfata audio |
1 / 1 |
| Interfata retea |
1 RJ45 10 M/100 M |
| Putere |
12 VDC, 2.0 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A, class4)
Max.:18 W (IR Max.6 W) |
| Temoeratura de operare |
-30°C - 65°C |
| Indice protectie |
IP66 |
| Dimensiune |
Φ 165.9 mm × 290 mm |
| Greutate |
2.5 kg |
