| Senzor |
1/3", CMOS cu scanare progresiva |
| Rezolutie de inregistrare |
4 megapixeli (2K) |
| Lentila |
4mm |
| Distanta DORI |
Detectie: 60m |
| |
Observare: 24m |
| |
Recunoastere: 12m |
| |
Identificare: 6m |
| Unghi pe orizontala (H) |
78.9° |
| Unghi pe verticala (V) |
39.6° |
| Ajustabilitate |
Pan: 0° ~ 360° |
| Shutter |
Auto/Manual, 1/100000s |
| Iluminare minima |
Color: 0.03Lux (F2.0, AGC ON) |
| |
0Lux cu IR activat |
| Reducerea zgomotului digital |
2D/3D DNR |
| Zi/Noapte |
Filtru IR-cut automat (ICR) |
| S/N |
>52dB |
| Distanta IR |
Pana la 20 de metri |
| WDR |
DWDR |
| Video |
Compresie Video: Ultra 265, H.265, H.264, MJPEG |
| |
Cadre pe secunda: |
| |
Stream Principal: 4MP (2592*1520), Max 20fps |
| |
Stream Secundar: 720P (1280*720), Max 20fps |
| |
Al treilea Stream: D1 (720*576), Max 20fps |
| HLC |
DA |
| BLC |
DA |
| OSD |
Pana la 4 OSD-uri |
| Masca de confidentialitate |
Pana la 4 zone |
| ROI (zona de interes) |
Pana la 2 zone |
| Detectie la miscare |
Pana la 4 zone |
| Functii IVS |
Detectare intrus, Detectare de miscare, Alarma intemperii, Detectia unui intrus intr-o zona predefinita |
| Retea |
Protocoale: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS |
| |
Compatibilitate: ONVIF (Profile S, Profile T), API |
| Interfete |
Retea: 10/100M Base-TX Ethernet |
| |
Card microSD: DA |
| General |
Alimentare: DC 12V±25%, PoE (IEEE 802.3af) |
| |
Consum: Max 4W |
| Dimensiuni (L x l x i) |
167.3 x 62.9 x 62.7mm (6.6” x 2.5” x 2.5”) |
| Greutate |
0.45kg (0.99lb) |
| Temperatura optima de functionare |
-30°C ~ 60°C (-22°F ~ 140°F), Umiditate: ≤95% RH (fara condensare) |
| Index de protectie |
IP67 |
| Buton Reset |
Da |
