Model No.

SAF-1MVIR

Solutie

OV9712+DM365– 1 Megapixel HD

Resolutie

Main Stream:1280×720;Sub Stream:704×576,352×288;

Iluminare minima

3300mV/Lux-sec

S/N Ratio

39db

Mod focus

Manual

Day/Night

IR cut filter IRC

Interfata

Iesire video

1 iesire analog  PAL/NTSC

Retea

1 RJ45 10/100M

Control IR LED

Auto / manual

Auto Iris

N/A

Audio

N/A

POE

N/A

PTZ

N/A

Alarm

N/A

Shortage

N/A

Wifi

N/A

Lentila

Lentila

2 Megapixel HD 2,8-12 mm

Parametrii retea

Delay

< 0.25S

Frame Rate

25FPS ( 1-25 FPS adjustable);

Compresie Video

H.264 ,dual stream ( 0.1M-6Mpbs)

Protocol

Protocoale :RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP

Onvif

Suporta Onvif 2.0

Acces user

Multi-user

Camera

IR LEDs

￠5X35PCS 30M IR Distanta

Day/Night

Auto(ICR)/Color/B/W

Compensare lumina

BLC / HLC / WDR (128dB)

Balans la alb

Auto

Gain Control

Auto/Manual

Noise Reduction

2D

General

Alimentare

DC 12V/1A

Umiditate

0%-90%RH,Without Condensation

Greutate

1,2 Kg

Functii principale

1.Control automatic pe imagine: AWB,AGC,AEC,ABLC

2.Suporta acces si configurare din browser IE

3.Suporta Dual Stream

4.Suporta Chroma,Brightness,Saturation,Electric Zoom Configuration

5.Suporta transmisie real-time

6.Suporta DDNS,UPNP , Onvif 2.0, IR-Cut Switch
