| System Security | Supports there-level account, password, user authority management. |
| OS | Embedded Linux OS |
| Processor | Hi3516C |
| P2P (Free) | No need to preset camera, Offer free P2P, Plug&play, Support QR code scanning to view |
| Onvif Protocol | Support ONVIF Protocol |
| Multi-device function | Support 12 language remote surveillance, record, alarm, wifi setting etc. |
| PC client | Support remote multi-devices monitor, record, alarm etc; |
| Support Windows and Mac OS |
| Cell Phone View | Self R&D APP, Support iPhone,Android smart phone |
| TF Card Record | INCLUS 64GB |
| Lens Type | 3.6MM |
| IR-CUT | Build-in IR CUT, no color cast,auto switch when IR on |
| Image Compression | H.264/MJPEG |
| Sensor | 1/2.7" Progressive Scan 2MP CMOS |
| Video Parameters | Brightness, Contrast,Saturation,Exposure,sharpness can be adjusted |
| Image Frame Rate | 50Hz:25fps/60HZ:30fps (1920×1080) |
| First Stream | 1080P(1920×1080), 960P(1280x960),720P(1280x720) |
| Second Stream | VGA-(640x352),(320x176) |
| Third Stream | (320x176) |
| Night Visibility | 6 Led lights,night vision up to 15 meters |
| Lux | IR ON 0 LUX |
| Motion Detect | Support 4 Independent detection areas(Sensitivity can be adjustd 1-100) |
| Alarm Action | Support Email Photo Alert,Snapshot and Record uploaded to FTP |
| Ethernet Interface | One 10/100Mbps RJ-45 |
| Supported Protocol | TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc. |
| Online Visitor | Support Max 6 visitors at the same time |
| (First Stream:3 visitors;Second Stream:3 visitors) |
| IP Mode | Dynamic IP address, static IP address(DHCP) |
| Online Visitor | Support Microsoft Win XP/Win7/Win8/ win10/Mac OS. |
| Browser | Support Internet Explorer 8.0-11.0, FireFox,Google Browser |
| One key setting Function | Support one key setting function connect WIFI |
| Wireless Standard | WIFI, 802.11b/g/n |
| OSD | Support the OSD name, date and time info superposition(Open/Off) |
| Product Type | Outdoor Use |
| Power | DC5V/2A |
| Working Temperature | -10~50 °C |
| Working Humidity | 95% RH |
| Size | Item: 148 x 60mm (HxW); Packaging: 175 x78 x95 mm (LxWxH) |
| Weight | N.W.: 289g G.W.: 461g (Note:Actual Weight Final) |
