Fisa tehnica

Modul Termic

• Senzor: Vanadium Oxide Uncooled Focal Plane Arrays
• Rezolutie maxima: 384 x 288 pixeli
• Lentila (Distanta focala): 50mm
• Unghi de vizualizare: 7.47° x 5.61°
•  50fps (384 x 288)

Camera

• Senzor: 1/1.9 inch Progressive Scan CMOS
• Sensibilitate: 0.002 LUX (0 LUX cu IR pornit)
• Lentila varifocala: 5.7 - 205.2 mm
• Zoom Optic: 36x
• Zoom Digital: 16x
• Unghi de vizualizare: 58.7°-2°
• Functii speciale: WDR (120dB), AWB, IR Cut, Defog, 3D DNR, VCA, PTZ
• Masurarea temperaturii: de la -20°C pana la 150°C (acuratete ±8°C)
• Detectie incendiu: pana la 10 zone
• Distanta iluminator IR: 200m
• Ajustare intensitate IR
• Main Stream:
• Optic: 30fps(1920× 1080)
• Distanta detectie autovehicule: 4510m
• Distanta recunoastere autovehicule: 1127m
• Distanta identificare autovehicule: 564m
• Distanta detectie persoane: 1471m
• Distanta recunoastere persoane: 368m
• Distanta identificare persoane: 184m
• Distanta VCA persoane: 360m
• Distanta VCA autovehicule: 1029m
• Masurarea temperaturii (Obiect 2x2m): 1170m
• Masurarea temperaturii (Obiect 1x1m): 590m
• Detectie foc (Obiect 2x2m ): 2940m
• Detectie foc (Obiect 1x1m): 1470m
• Compresie video: H.264/MJPEG/MJPEG4
• Compresie audio: G .711u/G.711a/G.722.1/MP2L2/G.726/PCM
• Protocol: IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,I GMP,ICMP,DHCP, PPPoE, Bonjour
• Utilizatori: maxim 32 (pe 3 nivele: Admin, operator, utilizator)
• Intrare/iesire alarma: 7/2
• Intrare audio: LINE_IN / MIC Input
• Reta: RJ-45 (10/100M)
• Capacitate de stocare: card microSD de pana la 64GB (cardul nu este inclus)
• Port RS485: Half-Duplex; HIKVISION, PELCO-P and PELCO-D Self-adaptive
• Stergator atasat
• Alimentare: 24V AC
• Temperatura de functionare: -40°C pana la +60°C
• Grad de protectie: IP66, TVS 6000V
• Greutate: 8Kg
