| Camera |
|---|
| Senzor de imagine: | senzor CMOS cu scanare progresiva 1/3" |
| Rezolutia maxima: | 2048(H)x1536(V) |
| Sistem: | PAL |
| Luminozitate minima: | F1.6, AGC On: Color: 0.05 lux, B/W : 0.01 lux , 0 lux with IR |
| Balans de alb: | Auto/Manual/ATW/Interior/Exterior/lumina calda/lumina incandescenta |
| AGC: | Auto/Manual |
| BLC: | ON/OFF |
| HLC: | Da |
| Sistem anti-ceata: | Da |
| WDR: | DWDR |
| Shutter Time: | 50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
| Zi & Noapte: | ICR |
| Zoom Digital : | 16X |
| Masca de confidentialitate: | pana la 24 de masti de confidentialitate programabile |
| Focus Auto : | Auto / Semi-automatic / Manual |
| Lentila |
|---|
| Lentila varifocala: | 5,7-205mm , 36x |
| Viteza de zoom: | Aprox.4.5s(Optical Wide-Tele) |
| Unghi de vizualizare: | 60.6-3.68 degree (Wide-Tele) |
| Distanta minima de functionare: | 10-1500mm(Wide-Tele) |
| Apertura Range: | F1.6~F4.4 |
| Functia Pan & Tilt ( orizontala si verticala) |
|---|
| Interval miscare orizontala: | 360°endless |
| Viteza miscare orizontala: | Pan Manual Speed: 0.1°~160°/s,
Pan Preset Speed: 240°/s |
| interval miscare verticala: | -20°~90°(Auto Flip) |
| Viteza miscare verticala: | Tilt Manual Speed: 0.1°~120°/s,
Tilt Preset Speed: 200°/s |
| Zoom proportionat: | viteza de rotatie poate fi reglate de multiplii de zoom |
| Numar preset-uri: | 300 |
| Patrula: | 8 patrule diferite, pana la 32 de preset-uri pe patrula |
| Functie model (pattern): | 4 modele, cu timp de inregistrare de cel putin 10 minute pe model |
| Recuperarea setarilor in caz de pierdere a tensiunii: | Da |
| mod Park : | Preset / Patrula / model / scanare orizontala / scanare verticala / scanare random / scanare pe frame / scanare panoramica |
| PTZ Position Display: | ON/OFF |
| Freeze Frame: | Da |
| Smart-tracking: | Manual/ Panoramic/ Detectie intrus/ Trecere linie interzisa/ detectie zona predefinita/ detectie zona iesire
Detectare smart intre diferite scenarii de mai sus |
| Stergator: | Optional |
| Infrarosu |
|---|
| distanta IR : | 200m |
| unghi IR : | Adjustable by zoom |
| Alarma |
|---|
| Intrare alarma: | 7 Intrari |
| Iesire alarma: | 2 iesiri |
| Actiuni in caz de alarma: | Preset, Inregistrare pe card de memorie, iesire releu, notificare catre client |
| Intrare si Iesire |
|---|
| Iesire monitor: | 1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC |
| Intrare audio: | 1 Mic in/Line in interface
Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
| Iesire audio: | 1 Audio output interface
Line level, impedance: 600Ω |
| Retea |
|---|
| Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector |
| Rezolutie maxima: | 2048×1536 |
| Stream principal: | 50Hz: 25fps(2048×1536), 25fps(1920×1080), 25fps (1280×720) / 50fps(2048×1536), 50fps(1920×1080) |
| Stream secundat: | 50Hz: 25fps(704×576, 352×288, 176×144) |
| Al treilea Stream: | 50Hz:25fps(2048×1536), 25fps(1920×1080), 25fps (1280×720), 25fps(704×576), 25fps (352×288), 25fps (176×144) |
| Compresia imagini: | H.264 / MJPEG |
| ROI : | Suporta pana la 6 zone ajustabile |
| Compresia audio: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Protocoale: | IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Nr. de utilizatori simultan: | Pana la 20 de utilizatori |
| Three-Stream: | Da |
| Mini SD Card: | Suporta card memorie pana la maxim 128GB Micro SD/SDHC/SDXC |
| Utilizator/Host : | Pana la 32 utilizatori,3 nivele: Administrator, Operator si utilizator |
| Masuri de siguranta: | Autentificare utilizator (ID and PW),
Autentificare Host(MAC address)
filtrare adresa IP |
| Client GUI |
|---|
| Control Camera : | Pan/Tilt, Zoom, Focus, Centrare cu click, Zoom cu ajutorul mouse-ului, Iris, preset-uri prin programare , mod automat |
| Display Data si Timp : | Timp: Saptamana: Data, 6 formate diferite pentru client |
| Client: | Support iVMS-4200 |
| Browser de internet: | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language |
| General |
|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Limba meniu: | English |
| Alimentare: | 24 VAC & Hi-PoE |
| Consum: | Max.60W |
| Temperatura optima / umiditatea : | -40°C ~ 65°C (-40°F ~ 149°F) |
| Factor de protectie: | IP66 standard (dome exterior), antivandal IK10,
TVS 6,000V protectie impotriva fulgerari, protecție împotriva supratensiunii și protecție tranzitorie de tensiune |
| Mountabil: | Montabil pe diverse braturi |
| Dimensiuni: | Φ266.6(mm)×365.2(mm) |
| Greutate (aprox.): | 8kg (approx.) |
| Optiune montabila: | Acest produs include un suport de perete montabil 1602ZJ |
