Camera |
Senzor | 1/3", 8.0 megapixel, progressive scan, CMOS |
Lentile | [email protected] |
Distanta DORI (m) | Detectare 84 Observare 33.6 Recunoastere 16.8 Indentificare 8.4 |
Unghi de vizualizare (I) | 112.7° |
Unghi de vizualizare (V) | 60.1° |
Unghi de vizualizare (D) | 146.5° |
Declansare | Auto/Manual, 1~1/100000 s |
Ajustarea unghiului | Pan: 0°~360°, Tilt: 0°~80°, Rotate:0°~360° |
Iluminare minima | Colour: 0.05 Lux (2.0, AGC ON), 0 Lux with IR |
Zi/Noapte | IR-cut filter with auto switch (ICR) |
Reducere digitala zgomot | 2D/3D DNR |
S/N | >56dB |
Distanta IR | Up to 30m (98 ft) IR range |
Lungime de unda | 850nm |
Control IR Pornit/Oprit | Auto/Manual |
Defog | Digital Defog |
WDR | 120dB |
Video |
Compresie video | Ultra 265, H.265, H.264, MJPEG |
H.264 Cod Profil | Profil de baza, Profil principal |
Cadre pe secunda | Main Stream:8MP (3840*2160): Max. 20 fps;5MP(2944*1656): Max. 30 fps; 4MP(2560*1440): Max. 30 fps; 2MP(1920*1080): Max. 30 fps Sub Stream:720P (1280*720): Max. 20 fps Third Stream:4CIF (704*576): Max. 20 fps |
Video Bit Rate | 128 Kbps~16 Mbps |
OSD | Pana la 4 OSD |
Privacy Mask | Pana la 4 |
ROI | Pana la 2 |
Detectie de miscare | Pana la 4 |
Imagine |
Balanta de alb | Auto/Outdoor/Fine Tune/ Sodium Lamp/Locked/Auto2 |
Reducere de zgomot | 2D/3D DNR |
Smart IR | DA |
Intoarcere | Normal/Vertical/Orizontal/180° |
Dewarping | NU |
HLC | DA |
BLC | DA |
Retea |
Protocoale | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL,QoS |
Integrare compatibila | ONVIF (Profile S+ Profile T), API |
Client | EZStation EZView EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
Interfete |
Retea | 10/100M Base-TX Ethernet |
Certificari |
Certificari | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
Alimentare | 12 V DC±25%, PoE (IEEE802.3 af) |
| Power consumption: Max 5W |
Dimensiuni (Ø x H) | Φ118×96mm (Φ4.6”×3.8”) |
Greutate | 0.33kg (0.73lb) |
Material | Metal + Plastic |
Mediu de lucru | -30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) |
Mediu de depozitare | -30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) |
Protectie supratensiune | 2KV |
Protectie exterior | IP67 |
