Senzor imagine | 1/1.8" Progressive Scan CMOS |
Iluminare minima | Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Viteza obturatorului | 1/3 s to 1/100,000 s |
WDR | 120 dB |
P/N | P/N |
Zi/Noapte | Filtru IR |
Unghi ajustare | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| |
LENTILA | |
Tipul lentilei | 4 mm |
Unghi vizual | Orizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° |
Iris Type | Fix |
Apertura | F1.6 |
| |
ILUMINARE | |
Iluminare suplimentara | IR |
Distanta IR | 80 metri |
| |
VIDEO | |
Rezolutie maxima | 3840 × 2160 |
Flux principal | 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| 60 Hz: 24 fps (3840 × 2160) |
| 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
Flux sencundar | 50 Hz: 25 fps (640 × 480, 640 × 360) |
| 60 Hz: 30 fps (640 × 480, 640 × 360) |
Al treilea flux | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Compresie Video | Principal: H.265/H.264/H.264+/H.265+ |
| Secundar: H.265/H.264/MJPEG |
| Al treilea: H.265/H.264 |
Bit Rate Video | 32 Kbps to 16 Mbps |
| |
NETWORK | |
Vizualizare simultana | 6 canale |
API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
Stocare | MicroSD 256 GB |
Web Browser | Plug-in required live view: IE 10+ |
| Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Local service: Chrome 57.0+, Firefox 52.0+ |
| |
IMAGINE | |
Functii de ajustare a imaginilor | BLC, HLC, 3D DNR |
| |
INTERFATA | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
Capturare fata | DA |
Detectare miscare | DA |
| |
GENERAL | |
Dimensiuni | Ø 105 mm × 290 mm (Ø 4.1" × 11.4") |
Greutate | 1510 g |
Temperaturi de operare | -30 ° - 60 ° |
Consum | 12 VDC ± 25%, reverse polarity protection |
| PoE: 802.3af, Class 3 |
| Alimentare: |
| 12 VDC, 0.88 A, max. 10.5 W |
| PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12 W |
Protectie | IP67 |
Material | Metal |
