| Senzor de imagine | 1/3" CMOS |
| Rezolutie maxima | 2560 (H) × 1440 (V) |
| ROM | 16 MB |
| RAM | 64 MB |
| Sistem de scanare | Progresiv |
| Viteza obturatorului electronic | Auto/Manual 1/3 s–1/100,000 s |
| Iluminare minima | 0.01 [email protected] (Color, 30 IRE), 0.001 [email protected] (B/W, 30 IRE), 0 lux (Iluminator pornit) |
| Raport S/N | >56 dB |
| Distanta de iluminare | Pana la 30 m |
| Control pornire/oprire iluminator | Auto; Manual |
| Numar iluminatori | 2 (IR LED) |
| Ajustare unghi | Pan: 0°–360°, Tilt: 0°–90°, Rotatie: 0°–360° |
| Tip lentila | Focala fixa |
| Montura lentila | M12 |
| Distanta focala | 3.6 mm |
| Deschidere maxima | F2.0 |
| Camp de vizualizare | H: 76°; V: 40°; D: 92° |
| Control iris | Fix |
| Distanta de focalizare minima | 1.4 m (4.59 ft) |
| Distanta DORI | Detectare: 85.2 m (279.53 ft), Observare: 34.1 m (111.88 ft), Recunoastere: 17.0 m (55.77 ft), Identificare: 8.5 m (27.89 ft) |
| Compresie video | H.265; H.264; H.264B; MJPEG (doar pentru sub stream) |
| Codec inteligent | Smart H.265+; Smart H.264+ |
| Rata cadrelor video | Flux principal: 2560 × 1440@(1–25/30 fps), Flux secundar: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Capacitate fluxuri | 2 fluxuri |
| Rezolutie | 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Control rata bit | CBR/VBR |
| Rata bit video | H.264: 32 kbps–4096 kbps, H.265: 12 kbps–4096 kbps |
| Zi/Noapte | Auto(ICR)/Color/B/W |
| BLC | Da |
| Evenimente de alarma | Deconectare retea; conflict IP; acces ilegal; detectie miscare; detectie audio; falsificare video; exceptie de securitate |
| Port retea | RJ-45 (10/100 Base-T) |
| Protocol retea | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; P2P |
| Interoperabilitate | ONVIF (Profile S; Profile T); CGI |
| Utilizator/Gazda | 6 (Latime de banda totala: 24 M) |
| Stocare | FTP |
| Browser | IE; Chrome; Firefox |
| Client mobil | iOS; Android |
| Securitate cibernetica | Configurare criptare; Executie de incredere; Digest; Jurnale de securitate; HTTPS; Actualizare de incredere; WSSE; Boot de incredere; Blocare cont; Generare si importare de certificare X.509; Criptare video |
| Alimentare | 12 VDC/PoE |
| Consum de energie | De baza: 1.4 W (12 VDC); 2.1 W (PoE), Max. (ICR switch+intensitate iluminator): 3.0 W (12 VDC); 4.2 W (PoE) |
| Temperatura de operare | –40 °C pana la +50 °C (–40 °F pana la +122 °F) |
| Umiditate de operare | ≤95% |
| Temperatura de stocare | –40 °C pana la +60 °C (–40 °F pana la +140 °F) |
| Umiditate de stocare | ≤95% |
| Grad de protectie | IP67 |
| Material carcasa | Plastic |
| Dimensiuni produs | 198.9 mm × 80.2 mm × 76.2 mm (7.83" × 3.16" × 3.00") (L × W × H) |
| Greutate neta | 0.25 kg |
| Greutate bruta | 0.37 kg |
