Senzor imagine | 1/3" Progressive Scan CMOS |
Iluminare minima | Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux cu IR pornit |
Lentila | fixa, 4 mm |
Unghi vizual | orizontal FOV 84°, vertical FOV 45°, diagonal FOV 100° |
Iluminare suplimentara | IR |
Distanta | 30 m |
DORI | 4 mm: D: 80 m, O: 31 m, R: 16 m, I: 8 m |
Rezolutie | 2688 × 1520 |
Flux principal | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Flux secundar | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Al treilea flux | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Compresie video | Flux principal: H.265/H.264/H.264+/H.265+ Flux secundar: H.265/H.264/MJPEG Al treilea flux: H.265/H.264 |
API | Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
Aplicatie mobila | Hik-Connect (Android si iOS) |
Functii ajustare imagine | BLC, HLC, 3D DNR, WDR |
Face detection | Da |
Protectie perimetru | Da |
Detectie miscare | Da |
Stocare | card microSD 512GB |
Retea | 1 RJ45 10M/100M |
Temperatura de operare | -30 °C si 60 °C |
Alimentare | 12 VDC ± 25%, reverse polarity protection PoE: 802.3af, Class 3 |
Consum | 12 VDC, 0.4 A, max. 5 W PoE (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
Index protectie | IK 10 si IP67 |
Material | aluminiu + plastic |
Dimensiuni | Ø110.8 × 84.7 mm |
Greutate | 720 g |
