Atentie! Camera nu dispune de slot pentru card microSD, astfel inregistrarile se vor stoca pe Hard Disk-ul NVR-ului.
Alimentarea este realizata la 12V clasic sau utilizand un cablu de retea PoE, simplificand procesul de cablare si reducand costurile de instalare.
| Senzor de imagine | 1/3.2" CMOS |
| Rezolutie maxima | 1920 (H) x 1080 (V) |
| ROM | 16 MB |
| RAM | 64 MB |
| Sistem de scanare | Progresiv |
| Viteza obturator electronic | Auto/Manual 1/3 s–1/100,000 s |
| Iluminare minima | 0.01 [email protected] (Color, 30 IRE); 0.001 [email protected] (B/W, 30 IRE); 0 lux (Iluminator pornit) |
| Ratie S/N | >56 dB |
| Distanta iluminare | Pana la 30 m (98.43 ft) (IR LED) |
| Control On/Off iluminator | Auto; Manual |
| Numar iluminatoare | 2 (IR LED) |
| Ajustare unghi | Pan: 0°–360°; Tilt: 0°–78°; Rotatie: 0°–360° |
| Tip lentila | Fix-focus |
| Montura lentila | M12 |
| Lungime focala | 3.6 mm |
| Apertura maxima | F2.0 |
| Camp vizual | H: 79°; V: 43°; D: 94° |
| Control iris | Fix |
| Distanta minima focalizare | 0.8 m (2.62 ft) |
| Distante DORI | Detectare: 55.0 m; Observare: 22.0 m; Recunoastere: 11.0 m; Identificare: 5.5 m |
| Compresie video | H.265; H.264; H.264B; MJPEG (doar pentru substream) |
| Codec inteligent | Smart H.265+; Smart H.264+ |
| Rata cadrelor video | Stream principal: 1920 x 1080@(1–25/30 fps); Substream: 704 x 576@(1–25 fps)/704 x 480@(1–30 fps) |
| Capacitate de streaming | 2 stream-uri |
| Rezolutii suportate | 1080p, 1.3M, 720p, D1, CIF |
| Control rata de biti | CBR/VBR |
| Rata de biti video | H.264: 32 kbps–4096 kbps; H.265: 12 kbps–4096 kbps |
| Zi/Noapte | Auto(ICR)/Color/B/W |
| BLC | Da |
| HLC | Da |
| WDR | DWDR |
| Balans de alb | Auto; natural; lampa stradala; exterior; manual; personalizat regional |
| Control castig | Auto |
| Reducere zgomot | 3D NR |
| Detectie miscare | OFF/ON (4 zone, dreptunghiulare) |
| Region of Interest (RoI) | Da (4 zone) |
| Iluminare inteligenta | Da |
| Rotatie imagine | 0°/180° |
| Oglindire imagine | Da |
| Masca de confidentialitate | 4 zone |
| Microfon incorporat | Da |
| Compresie audio | G.711a; G.711Mu; G.726; PCM |
| Evenimente alarma | Deconectare retea; Conflict IP; Acces neautorizat; Detectie miscare; Detectie audio; Manipulare video; Exceptii de securitate |
| Port retea | RJ-45 (10/100 Base-T) |
| Protocoale retea | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; P2P |
| Interoperabilitate | ONVIF (Profile S; Profile T); CGI |
| Utilizatori/Host | 6 (Latime de banda totala: 24 M) |
| Stocare | FTP |
| Browser | IE; Chrome; Firefox |
| Client mobil | iOS; Android |
| Securitate cibernetica | Configurare criptare; Executie de incredere; Digest; Jurnale de securitate; HTTPS; Actualizare de incredere; WSSE; Boot de incredere; Blocare cont; Generare si import certificare X.509; Criptare video |
| Alimentare | 12 VDC/PoE |
| Consum de energie | Basic: 1.2 W (12 VDC); 2.1 W (PoE); Max. (ICR switch+intensitate iluminator): 2.8 W (12 VDC); 4 W (PoE) |
| Temperatura de operare | –40 °C pana la +50 °C (–40 °F pana la +122 °F) |
| Umiditate de operare | ≤95% |
| Temperatura de stocare | –40 °C pana la +60 °C (–40 °F pana la +140 °F) |
| Umiditate de stocare | ≤95% |
| Protectie | IP67 |
| Material carcasa | Plastic |
| Dimensiuni produs | 103.2 mm x Φ109.9 mm (4.06" x Φ4.33") |
| Greutate neta | 0.24 kg (0.53 lb) |
| Greutate bruta | 0.38 kg (0.84 lb) |
