| Senzor imagine |
CMOS progresiv de 1/2.7" |
| Iluminare minima |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.02 Lux @ (F1.6, AGC ON) |
| Viteza obturator |
1/3 s la 1/100,000 s |
| Obturator lent |
Da |
| Diafragma automata |
Nu |
| Zi & Noapte |
Filtru IR cu taietura |
| Reducere zgomot digital |
3D DNR |
| WDR (Gama dinamica larga) |
DWDR |
| Ajustare unghi |
Pan: 0 grade la 360 grade, inclinare: 0 grade la 75 grade, rotire: 0 grade la 360 grade |
| Obiectiv |
Lungime focala de la 2.8 mm la 12 mm |
| Diafragma |
F1.6 |
| Focalizare automata |
Da |
| Camp de vizualizare |
FOV orizontal: 108.5 grade la 33.2 grade, FOV vertical: 57.5 grade la 18.8 grade, FOV diagonal: 130 grade la 38 grade |
| Montura obiectiv |
Ø 14 |
| IR |
Distant IR pana la 30 m |
| Lungime de unda IR |
850 nm |
| Standard de compresie video |
Principal: H.265/H.264 |
| |
Sub-stream: H.265/H.264/MJPEG |
| Tip H.264 |
Profil de baza/Profil principal/Profil inalt |
| H.264+ Tipul principal sustine |
|
| Tip H.265 |
Profil principal |
| H.265+ Tipul principal sustine |
|
| Rata de biti video |
De la 32 Kbps la 8 Mbps |
| Functionalitati inteligente |
Regiune de interes 1 regiune fixa pentru fluxul principal si fluxul secundar |
| Imagine |
Rezolutie maxima 1920 × 1080 |
| Flux principal |
Rata maxima de cadre 50Hz: 25fps (1920 × 1280, 1280 × 960, 1280 × 720) |
| |
60Hz: 30fps (1920 × 1280, 1280 × 960, 1280 × 720) |
| Sub-flux |
Rata maxima de cadre 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
| |
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Imbunatatire imagine |
BLC, 3D DNR |
| Setari imagine |
Saturatie, luminozitate, contrast, claritate, AGC, balans de alb ajustabil de catre software-ul client sau browser-ul web |
| Comutare zi/noapte |
Auto, programata, zi, noapte |
| Retea |
Declansare alarma Detectie miscare, tamperare video, deconectare retea, conflict IP, acces ilegal, eroare HDD, HDD complet |
| Stocare in retea |
Suport card microSD/SDHC/SDXC incorporat (128G), stocare locala si ANR |
| Protocoale |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Functii generale |
Resetare cu o singura apasare, puls, oglinda, protectie prin parola, mascare de confidentialitate, marcaj de apa, filtru de adresa IP |
| Versiune firmware |
5.5.52 API ONVIF (PROFIL S, PROFIL G), ISAPI |
| Vizualizare live simultana |
Pana la 6 canale |
| Utilizator/Gazda |
Pana la 32 de utilizatori |
| |
3 niveluri: Administrator, Operator si Utilizator |
| Client |
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
| Browser web |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
| Interfata |
Interfata de comunicare 1 RJ45 Ethernet auto-adaptabil 10M/100M |
| Stocare la bord |
Slot incorporat pentru card microSD/SDHC/SDXC, pana la 128 GB |
| Buton de resetare |
Da |
| Conditii generale |
-30 grade la 60 grade (-22 grade la 140 grade), umiditate: 95% sau mai putin (fara condens) |
| Sursa de alimentare |
12 VCC ± 25%, mufa coaxiala de 5,5 mm |
| PoE (802.3af, clasa 3) |
Consum de energie si curent 12 VCC, 0.9 A, Max: 10.5 W |
| |
PoE: (802.3af, 36 V la 57 V), 0.4 A la 0.2 A, Max: 12 W |
| Grad de protectie |
IP67 |
| Material |
Carcasa camerei: metal, baza inferioara: plastic |
| Dimensiuni |
Camera: Ø 129.4 mm × 116.4 mm (5.1" × 4.6") |
| |
Cu ambalaj: 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
| Greutate |
Camera: 560 g (1.2 lb.) |
| |
Cu ambalaj: 850 g (1.9 lb.) |
