Image Sensor | 1/2.9" CMOS |
Max. Resolution | 2688 (H) × 1520 (V) |
ROM | 128 MB |
RAM | 128 MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
Min. Illumination | 0.006 [email protected](Color,30IRE) |
| 0.0006 [email protected](B/W,30IRE) |
| 0 lux (Illuminator on) |
S/N Ratio | >56 dB |
Illumination Distance | Up to 60 m (IR), Up to 50 m (Warm light) |
Illuminator On/Off Control | Auto; Manual |
Illuminator Number | 2 (IR LED); 2 (Warm light) |
Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
Lens | Fixed-focal |
Lens Type | M12 |
Focal Length | 3.6 mm; 6 mm; 8 mm |
Max. Aperture | F1.6 |
Field of View | 3.6 mm: H: 84°; V: 42°; D: 101° |
IVS (Perimeter Protection) | Intrusion, tripwire (vehicle & human detect) |
Smart Search | Smart NVR intelligent search |
Video Compression | H.265; H.264; MJPEG (sub stream) |
Video Frame Rate | Main: 2688 × 1520@(1–20 fps) |
| Sub: 704 × 576@(1–25 fps) |
Stream Capability | 2 streams |
Resolution | 4M, 3M, 1080p, 720p, D1, VGA, CIF |
Bit Rate Control | CBR/VBR |
Video Bit Rate | H.264: 32 kbps–6144 kbps |
| H.265: 12 kbps–6144 kbps |
Day/Night | Auto(ICR)/Color/B/W |
BLC | Yes |
HLC | Yes |
WDR | 120 dB |
White Balance | Auto, manual, custom modes |
Gain Control | Auto, Manual |
Noise Reduction | 3D NR |
Motion Detection | OFF/ON (4 areas, rectangular) |
Region of Interest (RoI) | Yes (4 areas) |
Smart Illumination | Yes |
Image Rotation | 0°/90°/180°/270° |
Mirror | Yes |
Privacy Masking | 4 areas |
Audio | Built-in MIC |
Audio Compression | G.711a, G.711Mu, G.726, PCM |
Alarm | Various alarm events |
Network Port | RJ-45 (10/100 Base-T) |
Network Protocol | IPv4, IPv6, HTTP, TCP, UDP, etc. |
Interoperability | ONVIF (Profile S/T/G), CGI |
User/Host | 6 (Total bandwidth: 36 M) |
Storage | FTP, SFTP, Micro SD card (max. 256 GB) |
Management Software | SmartPSS Lite, DSS, DMSS |
Browser | IE, Chrome, Firefox |
Mobile Client | iOS, Android |
Cyber Security | Encryption, logs, account security, etc. |
Certification | CE-LVD, CE-EMC, FCC, UL/CUL, etc. |
Port | Audio Input/Output, Alarm Input/Output |
Power Supply | 12 VDC/PoE (802.3af) |
Power Consumption | Basic: 2W (12VDC); Max: 6.1W (12VDC) |
Operating Temperature | -40 °C to +60 °C |
Operating Humidity | ≤95% |
Storage Temperature | -40 °C to +60 °C |
Storage Humidity | ≤95% |
Protection | IP67, IK10 (optional) |
Casing Material | Metal |
Product Dimensions | 238.5 mm × 90.7 mm × 90.7 mm |
Net Weight | 0.72 kg (1.59 lb) |
Gross Weight | 0.95 kg (2.09 lb) |
