| Senzor de imagine | CMOS de scanare progresiva 1/3”, 4 megapixeli |
| Pixeli eficienti | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Sistem de scanare | Progresiv |
| Viteza obturator | Auto/Manual 1/3 s–1/100000 s |
| Iluminare minima | 0.03 Lux @ F2.0 |
| Distanța IR | 30 m (98.4 ft) |
| Control IR On/Off | Auto/Manual |
| Numar de LED-uri IR | 1 |
| Unghi de rotatie | Orizontal: 0°–360° |
| | Vertical: 0°–90° |
| | Rotatie: 0°–360° |
| Tip obiectiv | Fix-focal |
| Montura obiectiv | M12 |
| Lungime focala | 2.8 mm |
| | 3.6 mm |
| Apertura maxima | F2.0 |
| Camp vizual | 2.8 mm: |
| | Orizontal: 93° |
| | Vertical: 53° |
| | Diagonal: 111° |
| | 3.6 mm: |
| | Orizontal: 81° |
| | Vertical: 44° |
| | Diagonal: 95° |
| Tip iris | Diafragma fixa |
| Distantă de focalizare apropiată | 2.8 mm: 0.8 m (2.6 ft) |
| | 3.6 mm: 1.4 m (4.6 ft) |
| DORI Distance | Lentile Detectare Observare Recunoaștere |
| 2.8mm 50.0 m | (183.7 ft) |
| | 22.4 m (73.5 ft) |
| | 11.2 m (36.7 ft) |
| | 15.1 m (18.4 ft) |
| 3.6mm 80.0 m | (262.5 ft) |
| | 32.0 m (105.0 ft) |
| | 16.0 m (52.5 ft) |
| | 8.0 m (26.2 ft) |
| Compresie video | H.265; H.264; H.264B; MJPEG |
| Cod Smart | Da |
| Rata de cadre video | Main Stream: |
| | 2688 × 1520 (1 fps–20 fps) |
| | 2560 × 1440 (1 fps–25/30 fps) |
| Sub Stream: | |
| | 704 × 576 (1 fps–20/25 fps) |
| | 704 × 480 (1 fps–20/30 fps) |
| Capacitatea de streamuri | 2 streamuri |
| Rezolutie | 2688 × 1520 (2688 × 1520); |
| | 2560 × 1440 (2560 × 1440); |
| | 2304 × 1296 (2304 × 1296); |
| | 1080p (1920 × 1080); |
| | 1.3M (1280 × 960); |
| | 720p (1280 × 720); |
| | D1 (704 × 576/704 × 480); |
| | VGA (640 × 480); |
| | CIF (352 × 288/352 × 240) |
| Controlul ratei de biti | CBR; VBR |
| Rata de biti video | H.264: 32 Kbps–6144 Kbps |
| | H.265: 12 Kbps–6144 Kbps |
| Zi/Noapte Auto(ICR)/Culoare/Negru | Da |
| BLC | Da |
| HLC | Da |
| WDR | 120 dB |
| Balans de alb | Auto/natural/lampa stradala/in aer liber/manual/regional personalizat |
| Controlul de castig | Manual/Auto |
| Reducerea zgomotului | 3D DNR |
| Detectarea miscarii | Oprit/Activat (4 zone, rectangulare) |
| Regiunea de interes(RoI) | Da (4 zone) |
| Smart IR | Da |
| Rotația imaginii | 0°/90°/180°/270° (Suport 90°/270° cu rezolutie de 2688 × 1520) |
| Oglinzi | Da |
| Mascare de confidentialitate | 4 zone |
| Retea | RJ-45 (10/100 Base-T) |
| Protocol | HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; |
| | DHCP; DNS; DDNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; |
| | RTMP; Multicast; HTTPS; SFTP; 802.1x; ICMP; IGMP |
| Interoperabilitate | ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; |
| Utilizator/Gazda | 20 |
| Stocare pe margine | Dahua Cloud; FTP; SFTP; NAS |
| Browser | IE Chrome Firefox |
| Software de management | Smart PSS; DSS; DMSS |
| Telefon mobil | IOS; Android |
| Certificari | CE-LVD: EN60950-1 |
| | CE-EMC: Directiva de compatibilitate electromagnetica 2014/30/EU |
| | FCC: 47 CFR FCC Part 15, Subpart B |
| Alimentare | 12V DC/POE (802.3af) |
| Consum de energie | < 5.0W |
| Conditii de operare | -40°C pana la +55°C (-40°F pana la +131°F) /mai putin de ≤95% |
| Conditii de stocare | -40°C pana la +60°C (-40°F pana la +140°F) |
| Protectie la intrare | IP67 |
| Carcasa | Metal + Plastic |
| Dimensiuni | 162.6 mm × Φ70 mm (6.4" × Φ2.8") |
| Greutate neta | 0.22 kg (0.5 lb) |
| Greutate bruta | 0.35 kg (0.8 lb) |
