Sensor Parameters

Items / Specification

Cyclops635

Detector Type

Vox detector

Resolution / Pixel Spacing

640x512/12um

NETD

≤30mk@300k

Frame Rate

50Hz

Spectral Range

8～14μm

Lens

35mm (F#1.0, manual focus)

FOV

12.5°x 10°

Image Processing

Digital Zoom

1～6x continuous

Color Palette

5+

Noise Reduction

3D noise reduction

Image Enhancement

IDE、HDR

Display

OLED

0.39 inch，1024×768 resolution

Diopter Control

-5～+5

Eye Distance

40mm

Function

OLED

8 modes

Language

English

Reticle

6+, adjustable coordinates

Memory Card

16G

Heat Track

Yes

AI Distance Measurement

Yes

Laser Indicator

No

Photo, Record, Playback

Yes

GPS

Yes

Power

Battery Type

Internal Li-Ion Cell（18650 Li battery x 2）

Battery Life

Continuous working time≥ 12h

Interface

Type-C

Power charge, read data, output analog video

WI-FI

Two-way Wi-Fi connection, APP remote control

Environmental Parameters

Working Temperature

-20℃～+55℃

Protection Level

IP67，1 meter drop resistance

Physical Parameters

Weight

550g (with battery)

Size

67mm×63mm×190mm

Accessories

External Cable

Analog video cable, USB data cable

Other Accessory

Wrist strap, plush bag, user manual
