Senzor de imagine	1/2.8" CMOS
Pixel	2 MP
Rezolutie maxima	1920 (H) × 1080 (V)
ROM	128 MB
RAM	256 MB
Viteza obturator electronic	1/3 s–1/30,000 s
Sistem de scanare	Progressive
Iluminare minima	0.005 lux@F1.6 (Color, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (lumina IR)
Distanta de iluminare	150 m (492.13 ft) (IR)
Control On/Off iluminator	Zoom Prio; manual
Numar iluminatoare	4 (IR)
Lungime focala	4.8 mm–120 mm
Deschidere maxima	F1.6–F3.5
Camp vizual (FOV)	H: 60.6°–3.2°; V: 34.1°–1.8°; D: 69.4°–3.7°
Zoom optic	25×
Control focalizare	Auto; semi-auto; manual
Distanta minima de focalizare	0.1 m–2 m (0.33 ft–6.56 ft)
Control iris	Auto; manual
Distanta DORI	Detectare: 1655.2 m; Observare: 653.8 m; Recunoastere: 331.0 m; Identificare: 165.5 m
Interval Pan/Tilt	Pan: 0° pana la 360° (endless); Tilt: -15° pana la +90° (auto flip 180°)
Viteza de control manual	Pan: 0.1°–300°/s; Tilt: 0.1°–200°/s
Viteza presetata	Pan: 400°/s; Tilt: 300°/s
Preseturi	300
Tururi	8 (pana la 32 preseturi per tur)
Modele	5
Scanari	5
Memorie la intrerupere	Da
Miscare inactiva	Pattern; Preset; Scan; Tour
Protocol PTZ	DH-SD, Pelco-P/D (Auto recognition)
Rezolutie video	1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480)
Rata cadrelor video	1080p (25/30 fps); 720p (25/30/50/60 fps)
Zi/Noapte	Da
BLC	Da
WDR	120 dB
HLC	Da
Balans de alb	Auto; interior; exterior; tracking; manual; lampa de sodiu; lumina naturala; lampa stradala
Control gain	Auto; manual
Reducere zgomot	2D NR; 3D NR
Defog	Electronic
Zoom digital	16×
Rotire imagine	180°
Masca de confidentialitate	Da
Raport S/N	≥50 dB
Functie	Mod de iesire produs CVI, TVI, CVI, CVBS, AHD (CVBS este utilizat doar pentru depanare)
Certificari	CE: EN55032/EN55024/EN50130-4; FCC: Part15 subpart B, ANSI C63.4-2014; UL: UL60950-1+CAN/CSA C22.2, No.60950-1
Iesire analogica	1 canal (CVBS/CVI output, BNC)
RS-485	1 (plaja de baud rate: 1200 bps–9600 bps)
Intrare audio	1 canal (LINE IN, fire libere)
Intrari/iesiri alarma	2 (intrare valoare on-off: 0–5 VDC), 1 iesire
Linkare alarma	Scanare; presetare; tur; model; iesire digitala alarma
Eveniment alarma	Intrare alarma
Alimentare	24 VDC, 2.5 A ± 25%
Consum de putere	De baza: 10 W; Max.: 21 W (PTZ + iluminator)
Temperatura de operare	–40 °C pana la +70 °C (–40 °F pana la +158 °F)
Umiditate de operare	≤95%
Protectie	IP66; TVS 6000V protectie la fulgere; protectie la supratensiune; protectie la tranziente de tensiune
Dimensiuni produs	310.0 mm × Φ185.7 mm (12.20" × Φ7.31")
Greutate neta	3.9 kg (8.60 lb)
Greutate bruta	7.2 kg (15.87 lb)
